MediaTile 42"
Digital-Sign-in-a-Box™ '42



MediaTile’s 42” Digital-Sign-in-a-Box™ is a turnkey digital signage solution that provides an instant jumpstart into the rapidly emerging era of “narrowcasting” and digital signage networks. Centrally controlled by MediaTile's Web-based Broadcast Portal, MediaTile 42” Digital-Sign-in-a-Boxsystems include everything necessary to receive, store, and play digital promotions over the internet, including cellular broadband networks. Just plug them in to any power outlet and they instantly connect and begin to play promotions!



42" Digital-Sign-in-a-Box Specifications:

DISPLAY/AUDIO
  • 42” TFT HD LCD Display; 16.7 M Colors (8 bit)
  • 1280x720 (HD); 16:9 Aspect Ratio
  • 176º / 176º Viewing Angle; 1200:1 Contrast Ratio
  • Brightness: 500 cd/m²
  • Standard Screen or optional Touchscreen
  • “Auto-On” Following Power Interruptions
  • "Sleep mode" for off-hours power saving
  • Multiple video inputs; Switchable from Portal
  • Tamper-free design; no user-accessible controls
  • Stereo speakers optional



MEDIA PLAYER
  • Embedded fanless PC with Multimedia Player Software
  • 32 GB Storage available for user content
  • Support for Multi-zone Motion Graphics and RSS
  • “Files-Played” Logging (For Reports / Billing)
  • Remote Player Control via BroadCast Portal
  • Timed Check-in/ Status/ Files Played Reporting



NETWORK SUPPORT
  • Cellular Broadband (CDMA or GPS) - Option 1
  • Wi-Fi Network (802.11b/g) -Option 2
  • LAN Networking 10/100 Mbps LAN (RJ-45 Port)
  • Unlimited Data Transfer (for all above)
  • Systems come standard with Cellular and LAN support
FILES SUPPORTED
  • MPEG1-4 Hi DEF VIDEO (@ 6 MBS)
  • SWF FLASH (including Dynamic Flash support)
  • AVI VIDEO FILES (@ 5 MBS)
  • WMV VIDEO FILES (@ 5 MBS)
  • JPEG, JPG, PNG STATIC FILES
  • RSS for ticker (text crawl area)
  • Dynamic File URL Support
  • Microsoft PowerPoint PPT and PPS



ENCLOSURE/MOUNTING
  • Commercial grade, all metal enclosure
  • VESA standard 200mm x 200mm pattern
  • Secure access only



OPERATING PARAMETERS
  • Standard 110/220 VAC power
  • 400 Watts/ Display Max
  • 20 Watts/ Sleep Mode
  • Operating Temperature: Min. 41ºF Max. 104ºF



WEIGHT/DIMENSIONS

  • *Height/Width/Depth: 24-3/8"/40-1/4"/4-1/45"
  • Shipping Weight: 88lbs
  • Net Weight Installed: 74lbs

*without speakers
