MediaTile Kiosk-in-a-Box™, Marquee Edition



MediaTile’s Kiosk-in-a-Box™, Marquee Edition, delivers all the impact of a large screen digital signage broadcast network with the interactivity advantages of a kiosk system in one integrated package.  Now, in one easy to deploy and use environment, retailers and brands can attract consumers to their self-standing kiosk using video playlists on a high-definition, wide-screen display, while still having all requisite interactivity for their kiosk-based applications.



Kiosk-in-a-Box Marquee Edition Specifications:



DIGITAL SIGNAGE DISPLAY

  • 26”, 32” or 42” TFT HD LCD Display; 16.7 M Colors (8 bit)
  • 176º / 176º  H/V Viewing Angle
  • Brightness:500 cd/m2   1200:1 Contrast Ratio
  • 1280x720 (HD); 16:9 Aspect Ratio
  • “Auto-on” following power interruptions
  • “Sleep mode” for off-hours power saving
  • Tamper-free design; no user-accessible controls



KIOSK SYSTEM
  • Integrated Media Player
  • IR Touchscreen; non-scratch surface
  • 80 GB Storage available for user content
  • Support for Multi-zone, Motion Graphics and RSS
  • “Files-Played” Logging (For Digital Sign & Kiosk)
  • Touch-Track Interactivity Logging (For Kiosk)
  • Peripheral options: Barcode scanning (Line Scanner or omni scanner), MSR Magnetic Stripe Reader, Printer Port (via USB port)
  • Remote Player Control via BroadCast Portal
  • Timed Check-in with automatic monitoring & alerts



NETWORK SUPPORT
  • Cellular Broadband (CDMA or GPS) - Option 1
  • Wi-Fi Network (802.11b/g) -Option 2
  • LAN Networking 10/100 Mbps LAN (RJ-45 Port)
  • Satellite Networking; Via LAN (RJ-45 Port)
  • Unlimited Data Transfer (for all above)
  • Systems come standard with Cellular and LAN support
FILES SUPPORTED
  • MPEG1-4 Hi DEF VIDEO (@ 6 MBS)
  • SWF FLASH (including Dynamic Flash support)
  • AVI VIDEO FILES (@ 5 MBS)
  • WMV VIDEO FILES (@ 5 MBS)
  • JPEG, JPG, PNG STATIC FILES
  • RSS for ticker (text crawl area)
  • Dynamic File URL Support


ENCLOSURE/MOUNTING
  • Commercial grade, all metal enclosure
  • VESA standard 200mm x 200mm pattern
  • Secure access only



OPERATING PARAMETERS
  • Standard 110/220 VAC power
  • 500 Watts/ Display Max
  • 20 Watts/ Sleep Mode
  • Operating Temperature: Min. 41ºF Max. 104ºF
